文字或许能描绘宝钢电工钢上海35WW360产品的轮廓，但视频却能赋予它生命。每一帧都是一次全新的体验，每一次点击都是一次心灵的触动。快来观看，让产品活起来！


以下是:宝钢电工钢上海35WW360的图文介绍


鹿程国际贸易(平凉市分公司)是一家专业生产 汽车钢的厂家，公司集生产，销售于一体，在长期的实践中积累了丰富的经验。公司实力雄厚,技术完善,设备先进。公司始终坚持严格的质量管控，完善的售后服务技术，在全国各地建立了本地化的安装。主打产品 汽车钢。我们对产品、对客户负责的态度，将品质作为选择材料的先决条件，打造高质量产品。以优良的服务、赢得了广大用户的青睐。在同行业中处于领先位置。公司以团结开拓,诚信自强的企业精神为广大用户提供优质的产品与的服务。我公司厂房地理位置优越，交通便利。欢迎各界朋友来我公司考察或致电洽谈。




电工钢硅钢片半有机无铬超厚涂层L C6 C-6 EC-6 C-7涂层以有机成分为基础，添加较多的无机填料，以提高涂层绝缘性。涂层通常用于全工艺无取向电工钢，特别是大直径电机，如电站发电机。涂层可以改善钢的冲片性能，适合冲压叠片。涂层具有较高的层间电阻，能承受 300-550℃的涂层烧除处理，可用于重建电机定子时，去除电机定子绕组的绝缘层，也可用于风冷式或油浸式。涂层不能承受正常的应力退火。用户选择该涂层时，应考虑到在焊接过程中或涂层用于高温环境时，涂层会分解放出气体的情况。用户可以和供方协商确定该类涂层的层间电阻范围




电工钢硅钢片Electrical steel, also known as silicon steel sheet, is an indispensable metal material in the power, electronics, and military industries, and is also the largest functional material in production. It is mainly used as the iron core for various motors, generators, and transformers. Specific total loss (iron loss) is the total power consumed per unit mass of material when the magnetic polarization waveform remains sinusoidal, with a specific peak and frequency. The specific total loss is represented by the symbol P (Jm/f), in W/kg. Example: P1.5/50 represents the specific total loss at a maximum magnetic polarization intensity of 1.5T and a frequency of 50Hz. 3.2 Magnetic Polarization Q/BQB 480-20212 Magnetic polarization intensity refers to the peak magnetic polarization intensity of a specific magnetic field intensity when a sample is subjected to alternating magnetization. Its symbol is J (H), and the unit is T (Tesla). Example: J5000 represents the peak magnetic polarization intensity corresponding to a magnetic field intensity peak of 5000A/m. The material grades in this document are classified based on the nominal maximum specific total loss P1.5/50 (W/kg) at a magnetic polarization strength of 1.5T and a frequency of 50Hz, as well as the nominal thickness of the material. They are further divided into three categories based on product characteristics: ordinary type, stress relief annealing type, and high-efficiency type. Example 1: B35A210 represents a common non oriented electrical steel with a nominal thickness of 0.35mm, and the maximum nominal specific total loss value P1.5/50 is 2.10W/kg； Example 2: B35AR300 represents a stress relieved annealed non oriented electrical steel with a nominal thickness of 0.35mm, and the maximum nominal specific total loss value P1.5/50 is 3.00W/kg； Example 3: B35AH230 represents an efficient non oriented electrical steel with a nominal thickness of 0.35mm, and the maximum nominal specific loss value P1.5/50 is 2.30W/kg. Example 4: 35WW210 represents a normal type WW non oriented electrical steel with a nominal thickness of 0.35mm, and the maximum nominal specific loss value P1.5/50 is 2.10W/kg. Example 5: 35WH230 represents an efficient WH non oriented electrical steel with a nominal thickness of 0.35mm, and the maximum nominal specific loss value P1.5/50 is 2.30W/kg. The classification and code of insulation coatings shall comply with the provisions of Table 2. Table 2 Classification and Code of Insulation Coatings Type Code Characteristics of Insulation Coatings Semi organic Thin Coating A Improves Punching Performance and Has Good Weldability Semi organic Thick Coating H has Good Punching Performance and High Interlayer Resistance Semi organic Chromium Free Thin Coating K does not contain chromium and has good weldability Semi organic Chromium Free Thick Coating M does not contain chromium and has good insulation performance Semi organic Chromium Free Extreme Thick Coating J does not contain chromium and has excellent insulation performance Semi organic Chromium Free Ultra Thick Coating L does not contain chromium and has extremely high insulation performance Self adhesive Coating



点击查看鹿程国际贸易(平凉市分公司)的【产品相册库】以及我们的【产品视频库】
